SPOOKY  Laser Cutting and Etching System

SPOOKY II,    C02 SEALED OFF TYPE Laser cutter

1. ASSIST GAS FOR CUTTING WITH GAUGE AND MICRO FILTER VA

2. CUTTING HEAD WITH 2.5" FOCAL UNIT

3. COOLING SYSTEM (CHILLER)

4. BEAM EXPANDER

5. S/W (ICARO)

specification

working area    600*900mm

dimensions    1600*1600*1600mm

Z axis run    100mm

weight    450kg

speed    1000mm/sec

axis resolution    0.01mm

repeatibility    0.05mm

precision    0.1mm

interface    RS 232/C

power    ´Ü»ó 220V

input    3kw

compressor air    6 bar ÀÌ»ó

operating temperature    5-35

operating humidity    35-75%

laser source    50W / 100W

(cooling system)    ( WATER)

focal units    2.5"

laser guranteed    10000 hours

option

RASTER MODE(1200DPI)

CCD SYSTEM

CONVEYOR

DUAL HEAD

Application;

  FPD, Displays, Woods, Plastics, Teflon, Leathers, Textiles, Fabrics, Foams, PCBs, IC packages
